Build the Skew-Fade LFO Module!

Hosted by Żłob Modular
Sunday, Sept 13 @ 11am
Difficulty: Beginner

The Skew-Fade LFO is a 3hp analog low frequency oscillator eurorack module capable of a plethora of waveforms.

With three rate settings ranging from 3 minutes and 30 seconds a cycle (or  7 minutes a cycle with pcb jumper closed) up to audio range at 20hz. Triangle waves can be skewed between ramps and saws, and square waves puls width can be adjusted from inverted triggers to triggers. The LFO’s unique feature is voltage controlled cross fading through the (“Fade C.V.” in) between square/shark tooth\sine waveforms provided at the “Fade Out.” All outs are also influenced by the skew knob resulting in many complicated and asymmetrical possibilities at the “Fade Out.” It can even be self patched(ie triangle or square into fade cv) for an extended pallet of waveforms. The “Fade C.V.” in expects a bipolar voltage 10vpp to fade from square to sine with the fade pot at noon position. Bicolor led provides constant display of positive and negative voltage crossings.

The Panel is reversible, one side with graphics and soulless side with less graphics (not pictured).

Learn to solder! Żłob Modular will teach you basic soldering techniques and lead you through building the LFO module.

TO PARTICIPATE IN THIS WORKSHOP
You will need to purchase the $60 Skew-Fade kit from Żłob Modular HERE. Please select the "DIY Workshop Pickup" option during checkout to avoid paying shipping.

Some kits may be available for purchase on-site, however, you can secure your place in the workshop by pre-ordering your kit.
